Name: HRN_4orMoreFactors_SmoothOK

Display Field: Name

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P STYLE="text-align:Justify;"><SPAN><SPAN>The CL_SEGMENTS feature class models the approximate geometric centerline of road surfaces. Where there is a single roadway, a single segment is used to model the center of the road surface. If a road consists of separated (divided) roadways, separate segments are used to model the center of each road surface</SPAN></SPAN><SPAN><SPAN>.</SPAN></SPAN></P><P STYLE="text-align:Justify;"><SPAN><SPAN>Each roadway feature has a unique identifier stored in the 'CL_ID' field. These values are used to relate each feature to other feature classes within the Public Works feature dataset that model associated areas, shoulders, medians, and verges. The remaining fields store data pertinent to Public Works operations and HUTF collection processes, and primarily describe the name, type, traffic operation, function, construction, and dimensions of each roadway</SPAN></SPAN><SPAN><SPAN>.</SPAN></SPAN></P><P STYLE="text-align:Justify;"><SPAN><SPAN>The CL_SEGMENTS geometry supports the linear referencing of features with </SPAN></SPAN><SPAN STYLE="font-style:italic;"><SPAN>m</SPAN></SPAN><SPAN><SPAN>-coordinates. This feature class is not intended for geocoding applications, and therefore does not contain fields for the successful geocoding of feature locations, such as address ranges and zip codes.</SPAN></SPAN></P><P STYLE="text-align:Justify;"><SPAN><SPAN>The source of each feature's geometry and spatial definition is identified in the 'GeoSource' field. Most features are derived from 6" aerial imagery of the Town of Castle Rock, typically at a 1:200 scale. Features not collected from imagery are typically digitized from development record drawings, which are produced from the development firm's CAD data and recorded at a 1" = 50' scale or greater.</SPAN></SPAN></P><P><SPAN /></P></DIV></DIV></DIV>

Service Item Id: 05a431fdfae6432d9f394e93dced078b

Copyright Text:

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 3166798.633723885
YMin: 1546400.5477437228
XMax: 3199363.6807983816
YMax: 1580085.0709257275
Spatial Reference: 103013  (6428)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [255, 170, 0, 255]
Width: 3
Label: HRN
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: true

HasM: true

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Join_Count ( type: esriFieldTypeInteger, alias: Join_Count )
• TARGET_FID ( type: esriFieldTypeInteger, alias: TARGET_FID )
• Join_Count_1 ( type: esriFieldTypeInteger, alias: Join_Count )
• TARGET_FID_1 ( type: esriFieldTypeInteger, alias: TARGET_FID )
• Name ( type: esriFieldTypeString, alias: Roadway Name, length: 100 )
• ThruLn_Qty ( type: esriFieldTypeDouble, alias: Through Lanes )
• SpeedLimit ( type: esriFieldTypeSmallInteger, alias: Speed Limit )
• Score_Multilanes ( type: esriFieldTypeDouble, alias: Score_Multilanes )
• Func_Class ( type: esriFieldTypeString, alias: Functional Class, length: 30 )
• Score_FunClasses ( type: esriFieldTypeDouble, alias: Score_FunClasses )
• LocationType ( type: esriFieldTypeString, alias: LocationType, length: 255 )
• Score_Signal ( type: esriFieldTypeDouble, alias: Score_Signal )
• n_hard_accelerations ( type: esriFieldTypeInteger, alias: # Hard Accelerations )
• Score_HardAxl ( type: esriFieldTypeDouble, alias: Score_HardAxl )
• n_hardbrakes ( type: esriFieldTypeString, alias: n_hardbrakes, length: 255 )
• Score_HardBrake ( type: esriFieldTypeDouble, alias: Score_HardBrake )
• TYPE ( type: esriFieldTypeString, alias: TYPE, length: 34 )
• Score_Zoning ( type: esriFieldTypeDouble, alias: Score_Zoning )
• Threshold5 ( type: esriFieldTypeString, alias: Threshold5, length: 255 )
• SpeedLimit_1 ( type: esriFieldTypeSmallInteger, alias: Speed Limit )
• Score_HCurve ( type: esriFieldTypeDouble, alias: Score_HCurve )
• Category ( type: esriFieldTypeString, alias: Category, length: 1073741822 )
• Score_PublicComments ( type: esriFieldTypeDouble, alias: Score_PublicComments )
• TOTAL ( type: esriFieldTypeDouble, alias: TOTAL )
• MERGE_SRC ( type: esriFieldTypeString, alias: MERGE_SRC, length: 255 )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape_Length )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
